CDL Air Brakes Knowledge Test 2023

CDL Air Brakes Knowledge Test 2023: Try our free Commercial Driver’s License (CDL) Endorsements Air Brakes Permit Test. There are 30 sample questions and answers for better CDL written exam preparation.

Air brakes use compressed air to make the brakes work. You can apply all the braking force you need to each of the wheels of a heavy vehicle, even units pulling two or three trailers. Air brakes are a safe way of stopping large vehicles if the brakes are well-maintained and used properly. However, you must know more about air brakes than you need to know about the simpler brake systems used on light vehicles.

CDL Air Brakes Knowledge Test 2023

Test Name	CDL Practice Test 2023
Language	English
License	Endorsements Permit
Total Questions	30 MCQs
Test For	Commercial Driver License
Test Preparation	Air Brake Endorsements
Country	USA
Answers	Yes

0 votes, 0 avg

171

CDL Air Brakes Knowledge Test

CDL Air Brakes Knowledge Test

1 / 30

How often should you drain your air tanks?

A) Twice a week

B) Biweekly

C) At the end of each workday

D) Once a week

2 / 30

Which of the following pumps air into the air storage tanks?

A) Reservoir

B) Air compressor

C) Governor

D) Safety valve

3 / 30

What protects the tank and the rest of the air system from too much pressure?

A) Foot valve

B) Treadle valve

C) Safety valve

D) Draining valve

4 / 30

When should you NOT use the parking brakes?

A) If the brakes are very hot

B) When testing the spring brakes

C) If the brakes are wet during freezing weather

D) All of the above

5 / 30

A safety relief valve is installed in the first tank the air compressor pumps air to. The valve is usually set to open at what psi level?

A) 140

B) 130

C) 150

D) 160

6 / 30

Which of the following statements is true?

A) If you are gone only a short time, you do not need to use the parking brakes or chock the wheels.

B) If you park right after coming down a very steep grade, you should always use the parking brake.

C) It is not necessary to use the parking brake or chock your wheels if you are parked on a flat road surface.

D) Never leave your vehicle unattended without applying the parking brakes or chocking the wheels.

7 / 30

During the walkaround inspection, if a slack adjuster moves slightly more than an inch where the push rod attaches to it, then

A) it has the perfect amount of slack.

B) it probably needs adjustment.

C) the brakes will stop the vehicle very suddenly.

D) it will pass roadside inspection.

8 / 30

Before driving a vehicle with a dual air system, allow time for the air compressor to build up to 100 psi pressure in which of the following?

A) The primary system only

B) Both the primary and secondary systems

C) The secondary system only

D) It only has to build to 60 psi pressure in each system.

9 / 30

Which of the following is a proper technique in using controlled braking?

A) Pressing harder on the brakes when you feel the wheels sliding

B) Turning the steering wheel while braking

C) Putting the brakes on very hard to lock the wheels

D) Releasing the brakes if you need to make large steering adjustments

10 / 30

The low-air-pressure warning light must come on before the air pressure in the tanks falls below what psi level?

A) 60

B) 40

C) 30

D) 50

11 / 30

Most newer heavy-duty vehicles use dual air brake systems for safety. A dual air brake system has

A) two separate air brake systems and a single set of brake controls.

B) one air brake system and one brake control.

C) two separate air brake systems and two sets of brake controls.

D) one air brake system and two sets of brake controls.

12 / 30

Air brake systems are three braking systems combined. They are

A) parking, service, hand.

B) emergency, service, hand.

C) emergency, parking, service.

D) None of the above

13 / 30

Foundation brakes are used

A) at each axle.

B) at each wheel.

C) when parking.

D) only in emergencies.

14 / 30

ou are driving a vehicle at 55 mph on dry pavement under good traction and brake conditions. What is the approximate total stopping distance needed to bring your vehicle to a complete stop?

A) Two-and-a-half-times the length of the vehicle

B) Just over the length of a football field

C) Half the length of a football field

D) The length of the vehicle plus 20 feet

15 / 30

What should you do if the low-air-pressure warning comes on?

A) Use stab braking until you stop.

B) Drive to the nearest rest area.

C) Nothing; the vehicle will stop automatically.

D) Stop your vehicle as quickly as possible and safely park it.

16 / 30

When braking on downgrades,

A) coast downhill, then apply the brakes hard.

B) brake hard, then let up to cool brakes.

C) go slow enough so that a light, steady use of the brakes keeps you from speeding up.

D) use stab braking until wheels lock, then release.

17 / 30

Why, on long downhill grades, do experts recommend using a low gear and light steady pressure instead of on-again, off-again braking?

A) All of the above

B) You can keep vehicle speed constant in a low gear with light steady pressure.

C) Air usage is less with light steady pressure.

D) Brake lingings do not heat up as much.

18 / 30

The braking power of spring brakes depends on

A) proper adjustment.

B) traction

C) All of the above

D) how far the modulating control lever (if present) is moved.

19 / 30

The main purpose of the alcohol evaporator is to

A) remove alcohol from the compressor.

B) put alcohol in gas tanks.

C) remove alcohol from the storage tank.

D) put alcohol in the air system.

20 / 30

You have a fully-charged air system (125 psi). After turning off the engine and releasing the service brake, what are the maximum leakage rates per minute for both single and combination vehicles?

A) 4 psi for single, 5 psi for combination

B) 4 psi for both

C) 2 psi for single, 3 psi for combination

D) 3 psi for both

21 / 30

The brake system that applies and releases the brakes when the driver uses the brake pedal is the _____________ brake system.

A) parking

B) emergency

C) trailer

D) service

22 / 30

Pressing and releasing the brake pedal quickly and repeatedly

A) will help cool your brakes.

B) can let the air out faster than the compressor can replace it.

C) will stop your vehicle faster.

D) pumps air back into the air brake.

23 / 30

If your truck or bus has dual parking control valves, you can use pressure from a separate tank to:

A) release the spring emergency/parking brakes to move a short distance

B) brake harder if the main tank is getting low

C) balance the service brake system when you are parked

D) keep on about your business

24 / 30

Spring brakes do which of the following?

A) They will come on fully at 50 psi.

B) They are held by mechanical force.

C) They use air pressure to stop the vehicle.

D) They will not work if all the air leaks out of the air brake system.

25 / 30

During walkaround inspections of your vehicle, which parts of the air brake system should be checked?

A) Manual slack adjusters on S-cam brakes

B) Air hoses connected to brake chambers

C) Brake drums or discs

D) All of the above

26 / 30

The most common foundation brake is the

A) disc brake.

B) S-cam drum brake.

C) wedge brake.

D) front brake.

27 / 30

In checking that the spring brakes come on automatically, you should not

A) chock the wheels.

B) shut the engine off.

C) pull the parking brake control knob.

D) step on and off the brake pedal.

28 / 30

Total stopping distance for air brakes is longer than that for hydraulic brakes due to ________ distance

A) reaction

B) None of the above

C) brake lag

D) perceptive

29 / 30

Air brakes use

A) compressed air.

B) decompressed air.

C) cold air.

D) hot air.

30 / 30

Which of the following tells you how much pressure there is in the air tanks?

A) Application pressure gauge

B) Supply pressure gauge

C) Stop-light switch

D) Low-air-pressure warning signal

Your score is

The average score is 78%
